NEELE NESPD-L Integrated Shield Type 2 AC Surge Protective Device

NEELE NESPD-L Integrated Shield Type 2 AC Surge Protective Device

Series: NESPD-L
Type: Type 2 / Class II
Poles: 1P / 2P / 3P
Uc: 275V AC / 385V AC
In / Imax: 5/10kA, 10/20kA, 20/40kA
MOV: 20D / 25D / 34S
Up: ≤1.5kV / ≤2.0kV
Protection: IP20
Mounting: 35mm DIN Rail
Certification: CE

The NEELE NESPD-L Series is a Type 2 AC surge protective device featuring an integrated shield-style base structure with a clean and compact appearance.

Its plug-in modular design allows the protection module to be replaced separately, while the built-in thermal disconnection provides reliable protection against overheating.

Key Features

• Integrated shield-style base
• Clean and compact structure
• Plug-in replaceable module
• Built-in thermal disconnection
• Up to 40kA Imax
• 275V / 385V AC
• 1P / 2P / 3P available
• 35mm DIN rail mounting
• OEM color, logo and packaging available

Available Models

Applications

Residential distribution boards, commercial buildings, industrial panels, AC distribution systems, solar PV AC side and inverter protection.

FAQ

What is the main feature of the NESPD-L Series?
The NESPD-L uses an integrated shield-style base structure, giving the product a cleaner and more compact overall design.

Can the SPD module be replaced?
Yes. The plug-in module can be replaced separately without replacing the complete base.

What voltage ratings are available?
275V AC and 385V AC.

What colors are available?
White, orange-white, red, green and full orange are available. Custom colors can be provided for large OEM orders.
