NEELE NLEM1DC Thermal-Magnetic DC Molded Case Circuit Breaker Up to 250A

NEELE NLEM1DC Thermal-Magnetic DC Molded Case Circuit Breaker

Series: NLEM1DC
Product Type: DC Molded Case Circuit Breaker (MCCB)
Release Type: Thermal-Magnetic
Rated Current: Up to 250A
Poles: 3P / 4P
Rated Voltage: Up to 1000V DC
Protection: Overload & Short Circuit
Installation: Fixed / Screw Mounting
Application: Solar PV / Energy Storage / DC Distribution

The NEELE NLEM1DC Series is a thermal-magnetic molded case circuit breaker designed for DC power distribution and protection.

With rated currents up to 250A and 3P / 4P configurations, the series provides overload and short-circuit protection for photovoltaic, battery energy storage and other DC distribution systems.

Key Features

• Thermal-magnetic trip mechanism
• Overload and short-circuit protection
• Rated current up to 250A
• 3P / 4P available
• Up to 1000V DC
• Fixed mounting design
• Suitable for solar PV systems
• Suitable for battery energy storage
• Suitable for DC distribution panels
• OEM logo and packaging available

Model Naming Examples

NLEM1DC-125L/3300
125 frame · L grade · 3P · thermal-magnetic

NLEM1DC-125L/4300
125 frame · L grade · 4P · thermal-magnetic

NLEM1DC-250L/3300
250 frame · L grade · 3P · thermal-magnetic

NLEM1DC-250L/4300
250 frame · L grade · 4P · thermal-magnetic

如果你实际还有 M 级，就对应：

NLEM1DC-250M/3300
NLEM1DC-250M/4300

Applications

Solar PV systems, PV distribution cabinets, battery energy storage systems, DC distribution panels, inverter DC circuits and industrial DC power systems.

FAQ

What is the maximum rated current?
The NLEM1DC Series is available with rated currents up to 250A.

What pole configurations are available?
3P and 4P versions are available.

What protection does it provide?
It provides overload and short-circuit protection through a thermal-magnetic trip mechanism.

Can it be used in solar PV systems?
Yes. The NLEM1DC Series is designed for photovoltaic, energy storage and other DC distribution applications.

What is the difference between NLEM1 and NLEM1DC?
NLEM1 is designed for AC distribution, while NLEM1DC is designed specifically for DC circuits.
